Copland CSA70 Integrated Amplifier

from £2,988.00

The CSA70 is an integrated amplifier for music lovers. It delivers 70 watts per channel and has a wide range of inputs, including four digital inputs, three analogue inputs, a line-out function, a pre-out terminal, and a 6.3mm headphone output. It also includes an excellent phono preamp for vinyl enthusiasts.

Category Integrated Amplifier
Country Denmark
Manufacturer Copland

Colour:
Bluetooth Adapter:

The CSA70 is an integrated amplifier for music lovers. It delivers 70 watts per channel and has a wide range of inputs, including four digital inputs, three analogue inputs, a line-out function, a pre-out terminal, and a 6.3mm headphone output. It also includes an excellent phono preamp for vinyl enthusiasts.

Category Integrated Amplifier
Country Denmark
Manufacturer Copland



    • Free Delivery within Mainland UK.

    • 30-Day Money-back Guarantee

    • Returns Policy

  • Output power:2*70W into 8 ohms load. 2*130W into 4 ohms load.

    Minimum load: 2 ohms

    Analogue Inputs:

    1 * Phono / MM (RCA)
    3 * unbalanced (RCA)

    Digital Inputs:

    1 * coaxial S/PDIF.
    2 * optical S/PDIF.

    1 * USB. (Sampling rates up to 192 kHz.)
    1 * aptX HD Bluetooth (Optional Extra)

    Line output:

    1*unbalanced (RCA)
    1*Pre-out /unbalanced variable (RCA)

    Line input impedance: 50 K ohms

    Phono input impedance: 47 K ohms (MM)

    Phono input Capacitance: 200 pF

    Line Inputs sensitivity: 250 mV

    Phono sensitivity: 2.6 mV

    Frequency response: 4 Hz – 150 kHz -3d

    T.H.D: Better than 0.06 %

    Signal / noise IHF-A: Better than 90dB

    Phase: Non-inverting

    Headphone amp.Gain: 22 dB @ 100 ohms load impedance

    Headphone amp. Out imp:40 ohms

    Headphone amp. T.H.D: Better than 0.05 %Headphone amp.

    Freq. resp. 10 Hz – 150 kHz / -3dB

    Power consumption: Max.400 W

    Dimensions: 435mm (w) x 135mm (H) x 370mm (D)

    Shipping weight: 13 Kg.

Copland CSA 70 Integrated Amplifier

  • Created for the dedicated music lover, the CSA70 is designed to provide exceptional audio performance that belies its power rating and price. The CSA70 provides four digital inputs, three analogue inputs, line out function, as well as pre-out terminal, front facing 6.3mm headphone output, and a 70 Watts per channel power amplifier that will surprise users who thought their speakers were power hungry. For the vinyl enthusiast, we have included an excellent phono pre-amplifier.

  • Contrary to its bigger brothers, CSA100/CSA150 the CSA70 does not employ tubes in the line stage. The CSA70 preamplifier section is a solid stage architecture with vanishingly low distortion. The CSA70 boasts the same power amplifier technology as the CSA100/CSA150 with a feedback structure inherently faster than conventional amplifiers and a wide large-signal frequency response. The amplifier is ruggedly constructed and designed to deal with the most awkward of dynamic loads that may be presented by the loudspeakers, and this contributes to the amplifier’s excellent transient handling capability.
