Copland CSA150 Integrated Amplifier

from £4,988.00

The CSA150 is a high-power integrated amplifier from Copland. It offers 150 watts per channel and four digital inputs, five analogue inputs, and a phono input. It is based on the CSA100 but has been upgraded with a larger toroidal transformer, a separate fully regulated power supply for the power amplifier driver stages, and an increased heat sink area.

The Copland CSA150 is a powerful and versatile amplifier that can be used with a wide range of speakers and sources.

Category Integrated Amplifier
Country Denmark
Manufacturer Copland

Colour:
Bluetooth Adapter:

The CSA150 is a high-power integrated amplifier from Copland. It offers 150 watts per channel and four digital inputs, five analogue inputs, and a phono input. It is based on the CSA100 but has been upgraded with a larger toroidal transformer, a separate fully regulated power supply for the power amplifier driver stages, and an increased heat sink area.

The Copland CSA150 is a powerful and versatile amplifier that can be used with a wide range of speakers and sources.

Category Integrated Amplifier
Country Denmark
Manufacturer Copland



  • Output power:2*150 W into 8 ohms load.

    Minimum load: 2 ohms

    Analog Inputs:

    1*balanced (XLR)

    3*unbalanced (RCA)

    Digital Inputs:

    1*coaxial S/PDIF.

    2*optical S/PDIF.

    1* USB.

    1* aptX HD Bluetooth (Optional Extra)

    Line output:

    1*unbalanced (RCA)

    1*Pre-out /unbalanced variable (RCA)

    Line input impedance: 50 K ohms

    Phono input impedance: 47 K ohms (MM)

    Phono input Capacitance: 200 pF

    Line Inputs sensitivity: 270 mV

    Phono sensitivity: 2.6 mV

    Frequency response: 10 Hz – 150 kHz -3dB

    T.H.D: Better than 0.04 %

    Signal / noise IHF-A: Better than 90dB

    Phase: Inverting

    Headphone amp.Gain: 22 dB @ 100 ohms load impedance

    Headphone amp. Out imp:40 ohms

    Headphone amp. T.H.D: Better than 0.05 %.

    Freq. resp. 10 Hz – 150 kHz / -3dB

    Vacuum tubes:1 pc. 6922

    Power consumption: Max.700 W

    Dimensions: 435mm (w) x 165mm (H) x 370mm (D)

    Shipping weight: 15 Kg.

    • Free Delivery within Mainland UK.

    • 30-Day Money-back Guarantee

    • Returns Policy

Copland CSA 150 Integrated Amplifier

• Employing the Copland double triode gain stage with MOS-FET buffering ensuring a tight interface between the tube and the solid-state parts of the amplifier.

• Immunity to mains fluctuations, load demands and noise interference by use of wide bandwidth power supply regulation, not only for the low-level stages of the amplifier, but also by active regulation of the power amplifier driver stages.

• D/A converter with multiple S/PDIF inputs, PCM, and DSD capabilities using the ES9018 Reference 32-bit DAC in quad-mono configuration, 8 mono to 2 stereo configurations.

• Besides the digital coax and optical inputs an additional Bluetooth aptX module makes airborne sources available in HD quality.

• RCA inputs as well as balanced XLR. For the vinyl enthusiast the CSA150 has RIAA input for MM cartridges.

• Alps Blue Velvet volume control

• Classic tape loop in/out function as well as pre-out terminal and a front facing 6.3mm headphone output.
