DAC Digital Inputs:
USB Audio: PCM 44.1~384K (24/32bit),
DSD 2.8~5.6MHz (64~128X)
Windows Vista /7 /8 /10 (32/64bit)
Mac-OS X and Linux with UAC2 without drivers
S/PDIF Input: 1 x COAX / 2 x Optical.
PCM 44.1~192K (32bit)
DAC Analog Output:
RCA. 2.0 V rms. @ 0dBFS
Frequency response: 20Hz~20 kHz (+/-0.2dB)
SNR DAC > 120dB
THD < 0.004%
Head Amp:
Valves: 2 x ECC88 / 6DJ8 / 6922
Output Head Amp / Headphones: max. 8.5 V rms
Output impedance / Headphones: 5.0 O
Output impedance / Line out / RCA : 100 O
Frequency response: 20Hz~100 kHz (+/-0.5dB)
SNR: 90 dB
THD < 0.02%
Gain Head Amp: 10 dB
Power Consumption: 25W
Weight: 3.8Kg
Dimensions: 200 x 280 x 115 mm. W x D x H
-
Free Delivery within Mainland UK.
30-Day Money-back Guarantee
Returns Policy
Copland DAC215 Headphone Amplifier
HIGH-RES DAC, PRE-AMP & HEADPHONE AMP
The Copland DAC215 is a high-performance DAC that can process audio data of extremely high resolution. It is ideal for use with a computer, as it can bypass the source device's internal audio circuitry and deliver a detailed, transparent, and musical sound.
It features an ESS ES9018 Reference 32-bit DAC in quad-mono configuration, as well as a pair of ECC88 vacuum tubes in the headphone amplifier stage. It has a variety of digital inputs, including asynchronous USB, S/PDIF, and AES/EBU, as well as an analogue input. It also has two analogue outputs (fixed and variable) and a front-panel headphone output.
The DAC215 can be used for headphone playback or as a high-end preamplifier with volume control. The volume control and pre-amplifier functionality can be bypassed for pure DAC mode..
